| Coverage (Nominal -6 dB) V | 80° |
| Depth | 215.9mm (8.5") |
| Frequency Response (-10 dB) | 65 - 20000Hz |
| Height | 309.89mm (12.2") |
| HF Power Handling | 1-inchWatts |
| HF Transducer | 1-inch |
| Input Connections | Spring Terminal |
| Internal Crossover | Yes |
| LF Power Handling | Two 4-inchWatts |
| LF Transducer | Two 4-inch |
| Max. SPL/1m (calc) | 115dB |
| Minimum Impedance | 6Ω |
| Nominal Impedance (Passive) | 8Ω |
| Power Rating | 400W |
| Sensitivity 1 W/1 m | 89dB |
| Speaker Type | Full-Range, Mid-High, Two-Way |
| System Power Handling (Continuous/Program/Peak) | 100//400Watts |
| Transformer Taps (Transformer Version Only) | 70 V: 3.75 W, 70 V/100 V:7.5 W, 15 W,30 W,8 Ω Bypass |
| Weatherized | Yes |
| Weight Net | 3.9kg (8.6 lbs) |
| Width | 175.26mm (6.9") |
